Labor-saving connector

A labor-saving joint (or quick joint, quick connector) is a device used to connect pipes or hoses, which can be quickly installed and disassembled. It usually consists of two parts, one fixed at one end of the pipe or hose, and the other On another pipe or piece of equipment, the two parts can be easily connected and disconnected with a twist or push of a button, without the use of tools.

Labor-saving joints are mainly used to solve the problem of difficult plugging and unplugging. It can reduce the operating force when inserting or pulling out, allowing users to easily connect or disconnect devices, thereby reducing the difficulty and burden of operation. It is usually used for frequent replacement, In the pipeline and hose system for cleaning or maintenance, such as liquid transmission, gas transmission, machine tool, metallurgy, papermaking, printing, textile, electronics, automatic production line and chemical processing, etc., various equipment and instruments can be easily connected and disconnected To save time and labor, and improve work efficiency.

ㆍWorking pressure range / 0~150 psi /0~9.9Kgf/cm2 (0~990 KPa)
ㆍNegative pressure /-29.5in Hg/-750 mmHg(-750 Torr)
ㆍOperating temperature range / 32°F~140°F / 0~60°C
ㆍLabor-saving joints can connect pipes instantly
ㆍThe connection with the pipe can be easily removed by pressing the sleeve
ㆍThe joint has been treated with Teflon and O-ring on the thread
ㆍNickel-plated brass body ensures anti-pollution performance and prolongs product life

---
