Pneumatic Coupler-Japanese Style

Facility / 功能
● One-Hand / Two-Hand Operation (單手操作 / 雙手操作)
● Safty Lock (安全鎖)
● Double Seal (雙面密封)
● Flow Controller (流量控制)
● Swivel / Fitting Plug (旋轉 / 快插公體)

Interchange / 互換性
● Nitto Kohki Hi-Cupla 200
● CEJN 315 Series
● Rectus 13

Standard / 規格
● Material(材質): Steel(鐵) / Brass(銅)
● Body size(本體尺寸): 1/4"．3/8"．1/2"．3/4"
● Bar/Working pressure range(使用壓力範圍): 0-15
● Bar/Max working pressure(最高使用壓力): 20
● Bar/Min burst pressure(最小爆破壓力): 150
● Seal material(密封材質): NBR
● Temperature of using range(使用溫度範圍): -20℃~+80℃
